RT97 Mini Compact GMRS Repeater
FREE SHIPPING (Except for pure batteries) ×

RT97 Mini Compact GMRS Repeater

In Stock Unavailable
SKU: A9150

Regular price $399.99

*GMRS frequency with FCC certification

*Small and compact

*Simply to installation

*LCD screen display

FREE shipping


Retevis RT97 Mini Compact GMRS Repeater

Retevis RT97 GMRS Repeater is an analog repeater with a simple structure and a compact design. use to expand the transmission range of walkie-talkies and mobile radios, it can over double your two way radios talking range, greatly improving your communication distance. It is also the best-selling GMRS repeater in the United States. It is widely used to build personal repeater stations, Emergency, home base stations, farm base stations, GMRS shared repeater stations, and some commercial purposes to extend the existing radio communication distance, covering signal dead areas, etc., is the most popular relay.

gmrs repeater

Retevis RT97 GMRS Repeater Features

  • Three Year Warranty
  • 10W duplexer, output power 5-8W.
  • GMRS, UHF, VHF, and Customize Frequency are selectable.
  • GMRS version with 8 default preset GMRS channels, can compatible with all Retevis GMRS radios last 8 GMRS repeater channels directly out of the package.
  • 16 Channels
  •  LCD screen display shows CTCSS/DCS; Bandwidth(Narrow/Wide); TX and RX frequency/Channel number; High/low power Indication; Repeater transit Indication; Key Lock.
  • Two buttons are convenient to switch channels and change CTCSS/DCS.
  • 260 Privacy Codes - Bring you safe calls without interruptions.
  • Support 24/7 working
  • bandwidth adjustable-wide and narrow band available.
  • Wall charge and vehicle power supply, you can also connect it to solar power.
  • 10W duplexer included.
  • 0-9 Relay Tail delay selectable
  • Transit function: on/off
  • 0-9 squelch level selectable
  • Auto/Manual Key Lock
  • Compatible with all GMRS radios
  • FCC ID: 2ASNSRT97
  • Dimensions-‎9.45 x 7.48 x 2.56 inches
  • Net lightweight: ‎3.68lb

Package Includes

  • 1X Retevis RT97 Repeater
  • 1 x Charger
  • 1 x Power Supply
  • 1 x Car Charger Cable
  • 1 x Programming Cable
  • 1 x User’s Manual

Small and compact, solid and dust-proof;

Simple and convenient installation, flexible operation, can be operated as fixed or mobile.

Note:

UHF/VHF Recommended Antenna: Retevis MA01

GMRS version Recommended Antenna: Retevis MR004

Recommended Low Coax Cable: CA31

Customize lead time: 2 weeks

If you choose the customize, please leave the Tx and Rx frequencies you want when ordering.

If you need the offset lower than 5mhz, please contact us first.

Technical parameters:

Specifications
Frequency Range  GMRS/TX:462.5500/RX:467.5500 / UHF/TX:463.3125/RX:453.3125 / VHF/TX:162.6125/RX:152.6125 / Customize​
Channel Capacity 16CH
Channel Spacing ±12.5KHz Narrow/±25kHz Wide
Operating Voltage DC12V ~24V
Operating Temperature -30°C~ +60°C
Frequency Stability ±2.5ppm
Antenna Impedance 50Ω
Dimension 260*210*70mm
Weight 1.66kg
Transmitter
Intermediate Frequency 160MHz / 465MHz
Power Output ≤10W
Modulation F3E
Spurious Emission -60dB or less
Maximum Frequency Deviation Wide: ±5kHz Narrow: ±2.5kHz
Audio Distortion 5% or less
FM Noise Wide:≤45dB Narrow :≤40dB
Receiver
Intermediate Frequency 150MHz / 455MHz
Sensitivity(12dB SINAD) 0.2μV (Wide) 0.25μV (Narrow)
Squelch Sensitivity 0.15μV (Wide) 0.2μV (Narrow)
Adjacent Channel Selectivity ≥ 70dB (Wide) / ≥65dB (Narrow)
Intermodulation ≥ 55dB
Spurious Rejection ≥ 55dB
Image Rejection ≥ 55dB
FM Ham and Noise ≤-45dB(Wide) / ≤ -40dB(Narrow)
Modulation Type F3E
Operating Bandwidth ≤±7KHz / ≤±5KHz
Audio Distortion ≤ 5%

Retevis RT97 Programming Software

Retevis RT97 English Manual
